Fujifilm to Present Latest Advanced Lithography Research at SPIE Advanced Lithography + Patterning 2026 Conference

TOKYO--(BUSINESS WIRE)--FUJIFILM Corporation will present the company’s latest research findings at SPIE Advanced Lithography + Patterning 2026 (SPIE 2026), taking place February 22-26, 2026, in San Jose, California. The international conference is organized by SPIE, the international society for optics and photonics.

As a leading supplier of high-quality materials to the global semiconductor industry, the conference is an opportunity to further highlight our industry-leading technology and Research & Development that helps drive semiconductor innovations

Share

As part of its growth strategy aiming to double revenue in the semiconductor materials business to 500 billion yen (3.26B $USD) by FY2030 compared with FY2024, Fujifilm is focusing on the fast‑growing advanced resist market—particularly for AI semiconductors—with the goal of expanding its market share.

At SPIE 2026, researchers from FUJIFILM Corporation will highlight progress in Extreme Ultraviolet (EUV)^*1 resist technologies, nanoimprint lithography (NIL)^*2 resists and PFAS‑free^*3 resists. These cutting‑edge technologies contribute to further miniaturization and performance improvement in semiconductor manufacturing and form a key pillar supporting Fujifilm’s materials business.

“As a leading supplier of electronic materials to the global semiconductor industry, including AI semiconductors, the advanced resist market provides a unique opportunity for our company and our One-Stop Solution philosophy for customers. Our SPIE presentations will provide attendees with a greater understanding of our capabilities in this area,” says Tetsuya Iwasaki, director, senior vice president, and general manager of Electronic Materials Business Division, FUJIFILM Corporation, Japan. “The conference is an opportunity to further highlight our industry-leading technology and Research & Development that helps drive semiconductor innovations.”

Specifically, researchers from FUJIFILM Corporation will report on enhanced defect‑reduction performance in negative‑tone EUV resists and progress in developing next‑generation photoresists compatible with high‑NA EUV exposure. These developments support high‑precision patterning required for state‑of‑the‑art semiconductor manufacturing at ever‑smaller dimensions. Progress in positive‑tone EUV resist development will also be shared, expanding the lineup to meet diverse customer needs. Additionally, Fujifilm will introduce new developments in UV-curable spin-coating NIL resists and its PFAS-free positive tone ArF^*4 immersion resist lineup, which addresses rising demand for alternative materials in line with the company’s global Sustainable Value Plan 2030.

Fujifilm Presentation Topics at SPIE 2026

• Feb. 23, 2:30 p.m.: Development of EUV CAR-NTD process with new organic solvent based-developer for scaling (View abstract, presenter & authors)
• Feb 24, 2:50 p.m.: Development of spin-coating UV-NIL resist for semiconductor device manufacturing (View abstract, presenter & authors)
• Feb 25, 4:00 p.m.: Challenges and progress of PFAS alternatives for ArF resist (View abstract, presenter & authors)
• Feb 25, 5:30 p.m.: Novel EUV photoresists for positive tone development (View abstract, presenter & authors)
